SPECIAL ORDER ONLY / CALL FOR DETAILS
Chamber & Seal Bars
Chamber Width x Length 29" x 27"
Height (Chamber + Dome/Lid = Total) 5" + 5.5" = 10.5"
Number of Seal Bars 2
Position of Seal Bars Left & Right
Seal Bar Length 2 x 26"
Distance between Seal Bars 24"
Seal: Flat (4mm) + Bag Trimmer
Unique Waffle-Pattern Sealing YES
Pop-Out Seal Bars YES
Independent Power to each Seal Bar YES
Performance
Pump Type Busch R5 Oil Rotary
Cycles per Minute* up to 3
Free Air Displacement 63 m³/h
Pump Power Rating 3 hp
Power Supply 208V / 3ph / 19A
Display & Controls
Water Resistant Digital Display
LED Full Description Display
Electronic Millibar Sensor
Customizable Programs 9
Operational Features
Programmable Sealing Time
Programmable Vacuum Time (%)
Excess Bag Cut-Off
High Volume Density Plates
Service
Indicating Display
1 Year Limited Warranty
Housing & Dimensions
Material Stainless 304
Lid Type Transparent with Dome
Width x Length 32" x 35"
Height (Lid open/closed) 58.25" / 41.25"
Working Height 35"
Locking Casters YES
Shipping Wt. 580lbs
Certificates
ETL Electrical
ETL Sanitation (NSF Standard)
Optional Features
Tray for Liquid
Gentle Air Return
Inert Gas Kit (4 Nozzles)
220V / 1ph / 22A / 63 m³/h
208V / 3ph / 18A / 100 m³/h
*Depends on type of product, film and operator ability.
Specifications may change without notice.
